Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
149
4. Select function (pre-selection) and functions of the digital input: "Function (pre-selection)"
and "Function" parameter boxess.
Use the information in the tables below when setting the pre-selection:
→ Table 6-17 Function assignment at function (pre-selection): "Free" (Page 144).
→ Table 6-18 Function assignment at function (pre-selection): " Ext. fault", "Ext. maint.
alarm", "Ext. maint. demand" or "Ext. maint. required" (Page 144).
→ Table 6-19 Function assignment at function (pre-selection): "Ext. funct. check"
(Page 145).
→ Table 6-20 Function assignment at function (pre-selection): "Calibration" (Page 145).
→ Table 6-21 Function assignment at function (pre-selection): "AutoCal" (Page 146).
→ Table 6-22 Function assignment at function (pre-selection): "Measuring range"
(Page 146).
→ Table 6-23 Function assignment at function (pre-selection): "Other functions"
(Page 147).
Additional parameter boxes are displayed, depending on the set pre-selection or function.
5. Set additional parameter boxes or check displayed values:
Additional param-
eter boxes
Measuring range Component Select component.
Calibration pool
1
Diverse
1)
Check the parameter assignment of the calibration pool
1)
The display refers to a specific calibration pool entry and includes: component(s), calibration
type, single/total calibration as well as the assigned measuring range.
Note
Effects of modified message texts
If you modify an existing message text, all the existing logbook entries will be overwritten
with the newly created text.
Setting MODBUS digital inputs (Page 249)
Linking digital inputs (Page 150)
