Functions
6-557SJ62 Manual
C53000-G1140-C121-1
1515 Normal Load
(Torque angle of
dir. Fct)
Inductive (135°)
Resistive (90°)
Capacitive (45°)
Inductive (135°) Angle of the directional limit lineXXXXX
1516 67 Direction Forward
Reverse
Forward Directional orientation of the 67
elements
XXXXX
1530 67 TOC User PU 67-TOC user defined character-
istic curve values
XX
1531 MofPU Res T/Tp 67-TOC reset user defined
curve values
X
Addr. LCD-Text Setting Options Default Setting Comments Configuration
Definite Time Only
IEC Curve
ANSI Curve
User Defined Pickup
User def. Reset
