SIPROTEC 4 Devices
4-77SJ62 Manual
C53000-G1140-C121-1
4.2.2 DIGSI
®
4 Tool
DIGSI
®
4 uses the familiar Windows operating environment.
User Guide In DIGSI
®
4 only the settings that are available within a specific device are shown in
the specific windows. If a protective feature is changed from disabled to enabled in the
Device Configuration, then the settings relevant to that feature become available.
Entering settings for SIPROTEC
®
4 devices is simplified due to many types of assis-
tance offered, such as context menus, pop-up lists for the selection of available op-
tions, and specific limits for the entry of numerical values.
Masking Inputs
and Outputs
(Configuration
Matrix)
A configuration matrix is used to mask the binary inputs, binary outputs, and LEDs.
Information to be saved in the various buffers and transmitted via the system interface
is also selected in this matrix. The setting options are presented in an easy-to-read
tabular format. Parts of the matrix can be minimized or expanded as desired to simplify
the displayed sections, and therefore the setting process. Filter functions can reduce
the size of the matrix to display only relevant information.
Passwords Password entry is required for tasks such as changing settings, executing control
commands, or exercising the test and diagnostics features. The passwords protect
against unauthorized access to these critical tasks.
Commissioning
Aids
DIGSI
®
4 simplifies commissioning with test functions for the binary inputs, outputs
and LEDs. Control of primary equipment can be done. The measured values of the
device can be viewed with the program. Waveform capture can be triggered with
DIGSI
®
4.
Help System The help system clarifies the individual functions and settings, and provides additional
support.
Note:
Detailed information about DIGSI
®
4 can be found in the DIGSI
®
4 instruction book,
order number E50417-H1176-C097.
