4-17SJ62 Manual

C53000-G1140-C121-1

SIPROTEC 4 Devices 4

This section provides an overview of the family of SIPROTEC

4 devices and the in-

tegration of the devices into process control systems. Principle procedures are provid-

ed for setting the devices, controlling primary equipment with the devices, and per-

forming general operations with the devices.

Please note the SIPROTEC

4 family of devices is described in general in this section,

and the examples shown may differ in detail from a specific device. Also, depending

on the version of the specific device, some of the functions discussed may not be

available.

Details about the extent of the functions of the devices, the individual settings, and the

representation structure of the system data are found in the following sections and the

DIGSI

4 instruction book.

4.1 General 4-2

4.2 Operator Control Facilities 4-5

4.3 Information Retrieval 4-8

4.4 Control 4-14

4.5 Manual Overwrite / Tagging 4-16

4.6 General Setting Procedure 4-17

4.7 Device Configuration 4-20

4.8 Configuration of Inputs and Outputs (Configuration Matrix) 4-21

4.9 Programmable Logic CFC 4-24

4.10 Power System Data 4-26

4.11 Setting Groups 4-27

4.12 General Device Settings 4-29

4.13 Time Synchronization 4-30

4.14 Serial Interfaces 4-31

4.15 Passwords 4-33
