6.3.2.6 Information List for Directional Ground Overcurrent Protection
1609 67N–TOC T– DIAL 0.50 ~ 15.00 5.00 sec Time dial setting, ANSI X
1610 67N–TOC RESET immediate
disk emulation
Disk emulation Characteristics of 67N-
TOC dropout
XX
1611 67N-TOC IEC Normal Inverse
Very Inverse
Extremely Inverse
Long Inverse
Normal Inverse Characteristic curve (IEC) X
X
X
X
1612 67N–TOC ANSI Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inverse
Extremely Inverse
Definite Inverse
Very inverse Characteristic curve (AN-
SI)
X
X
X
X
X
X
X
1613 MANUALCLOSE-
MODE
67N-2 instanta-
neously
67N-1 instanta-
neously
67N-TOC instanta-
neously
Inactive
67N-2 instanta-
neously
Selection of high speed
tripping element when
manual closing feature is
used
XXXXX
1614 67N active Always
with 79 active
Always Criteria for operation of
67N-2 element
XXXXX
1615 Normal Load
(Torque angle of
dir. fct)
Inductive (135°)
Resistive (90°)
Capacitive (45°)
Inductive
((135°)
Angle of the directional lim-
it line
XXXXX
1616 67N Direction Forward
Reverse
Forward Directional orientation of
the 67N elements
XXXXX
1630 M.of PU TD 67N-TOC user defined
characteristic curve values
XX
1631 I/IEp Rf T/TEp 67N-TOC reset user de-
fined curve values
X
Addr. LCD-Text Setting options Default Setting Comments Configuration
Definite Time Only
IEC Curve
ANSI Curve
User Defined Pickup
User def. Reset
F#
LCD-Text
Comment
2656 67N OFF 67N/67N-TOC switched OFF
2657 67N BLOCKED 67N/67N-TOC is BLOCKED
2658 67N ACTIVE 67N/67N-TOC is ACTIVE
2646 67N-2 picked up 67N-2 picked up
