Technical Data
10-4 7SJ62 Manual
C53000-G1140-C121-1
Switching Voltage 250 V
Permissible Current 1 A continuous
1
) UL–listed with the following nominal value:
120 V ac Pilot duty, B300
240 V ac Pilot duty, B300
240 V ac 5 A General Purpose
24 V dc 5 A General Purpose
48 V dc 0.8 A General Purpose
240 V dc 0.1 A General Purpose
120 V ac 1/6 hp (4.4 FLA)
240 V ac 1/2 hp (4.9 FLA)
10.1.4 Communications Interfaces
PC Front Interface – Connection front panel, non-isolated, RS 232,
9-pin DSUB port for connecting a personal
computer
– Transmission Speed min. 4800 Baud; max. 38400 Baud
Factory Setting: 38400 Baud; Parity: 8E1
– Maximum Distance of Transmission 15 meters / 49 feet
Rear Service–/Mo-
dem– Interface
– Connection isolated interface for data transfer
– Operation with DIGSI
®
4
– Transmission Speed min. 4800 Bd, max. 38400 Bd
Factory Setting: 38400 Bd
RS232/RS485
RS232/RS485 depends on order code
– Connection for flush mounted case rear panel, mounting location “C“
9 pin DSUB port
for panel-surface at the terminal on the case bottom
mounted case
– Test Voltage 500 V AC
RS232
– Maximum Distance of Transmission 15 meters / 49 feet
RS485
– Maximum Distance of Transmission 1 km / 3280 feet / 0.62 mile
Fibre Optical Link
– Connector Type ST–Connector
with flush-mounted case rear panel, mounting location “C“
with panel surface-
mounted case on the case bottom
– Optical Wavelength λ = 820 nm
