Functions
6-122 7SJ62 Manual
C53000-G1140-C121-1
Delays The time delays (Definite Time) entered at addresses , , and ,
allow the device to prioritize or order corrective actions based on the degree to which
the actual system frequency departs (upward or downward) from the nominal system
frequency.
Minimum Voltage The minimum voltage is set at address 9PLQ. If the positive sequence voltage
is less than this value, the frequency protection is blocked.
6.12.2.1 Settings for Frequency Protection
For 60 Hz systems:
For 50 Hz systems:
Addr. LCD-Text Setting Options Default Setting Comments
5401 FCT 81 O/U OFF
ON
OFF 81 Over/Under
Frequency Protection
5402 Vmin 40
~ 120 V 65 V Minimum required
voltage for operation
5404 81–1 PICKUP 55.50
~ 64.50 Hz 59.50 Hz 81-1 Pickup
5405 81–1 DELAY 0.00
~ 100.00 sec. 60.00 sec. 81-1 Time Delay
5407 81–2 PICKUP 55.50 ~ 64.50 Hz 59.00 Hz 81-2 Pickup
5408 81–2 DELAY 0.00
~ 100.00 sec. 30.00 sec. 81-2 Time Delay
5410 81–3 PICKUP 55.50
~ 64.50 Hz 57.50 Hz 81-3 Pickup
5411 81–3 DELAY 0.00 ~ 100.00 sec. 3.00 sec. 81-3 Time delay
5413 81–4 PICKUP 55.50
~ 64.50 Hz 61.00 Hz 81-4 Pickup
5414 81–4 DELAY 0.00
~ 100.00 sec. 30.00 sec. 81-4 Time delay
Addr. LCD-Text Setting Options Default Setting Comments
5401 FCT 81 O/U OFF
ON
OFF 81 Over/Under
Frequency Protection
5402 Vmin 40
~ 120 V 65 V Minimum required
voltage for operation
5403 81–1 PICKUP 45.50
~ 54.50 Hz 49.50 Hz 81-1 Pickup
5405 81–1 DELAY 0.00
~ 100.00 sec. 60.00 sec. 81-1 Time Delay
5406 81–2 PICKUP 45.50 ~ 54.50 Hz 49.00 Hz 81-2 Pickup
5408 81–2 DELAY 0.00
~ 100.00 sec. 30.00 sec. 81-2 Time Delay
5409 81–3 PICKUP 45.50
~ 54.50 Hz 47.50 Hz 81-3 Pickup
5411 81–3 DELAY 0.00 ~ 100.00 sec. 3.00 sec. 81-3 Time delay
5412 81–4 PICKUP 45.50
~ 54.50 Hz 51.00 Hz 81-4 Pickup
5414 81–4 DELAY 0.00
~ 100.00 sec. 30.00 sec. 81-4 Time delay
