Siemens SIPROTEC 7SJ62 Instruction Manual

Technical Data
10-8 7SJ62 Manual
C53000-G1140-C121-1
– Damped Oscillations 2.5 kV (Peak Value), polarity alternating
similar to IEC 60694–4–12, 100 kHz, 1 MHz, 10 MHz and 50 MHz,
IEC 61000–4–12 R
i
= 200 Ω
EMC Tests For
Noise Emission
(type test)
Standard: EN 50081–1 (Generic Standard)
– Radio Noise Voltage to Lines, 150 kHz to 30 MHz
Only Power Supply Voltage Limit Class B
IEC–CISPR 22
– Radio Noise Field Strength 30 MHz to 1000 MHz
IEC–CISPR 22 Limit Class B
– Harmonic Currents Device is to be assigned Class D
on the Network Lead At 230 V
AC (applies only for devices with >50VA power
IEC 61000–3–2 consumption)
– Voltage Variations Limits are observed
and Flicker on the Network Lead
at 230 V
AC
IEC 61000–3–3
10.1.6 Mechanical Stress Tests
Vibration and
Shock Stress Dur-
ing Operation
Standards: IEC 60255–21 and IEC 60068
– Vibration Sinusoidal
IEC 60255–21–1, Class 2 10 Hz to 60 Hz: ±0.075 mm Amplitude;
IEC 60068–2–6 60 Hz to 150 Hz: 1 g acceleration
frequency sweep rate 1 Octave/min
20 cycles in 3 orthogonal axes.
– Shock Half-sine shaped
IEC 60255–21–2, Class 1 acceleration 5 g, duration 11 ms,
IEC 60068–2–27 3 shocks in each direction of
3 orthogonal axes
– Seismic Vibration Sinusoidal
IEC 60255–21–2, Class 1 1 Hz to 8 Hz ± 3.5 mm Amplitude
IEC 60068–3–3 (horizontal axis)
1Hz to 8Hz: ± 1.5 mm Amplitude
(Vertical axis)
8 Hz to 35 Hz: 1 g acceleration
(horizontale axis)
8 Hz to 35 Hz: 0.5 g acceleration
(Vertical axis)
Frequency Sweep Rate1 Octave/min
1 cycle in 3 orthogonal axes
Vibration and
Shock Stress Dur-
ing Transport
Standards: IEC 60255–21 and IEC 60068–2
– Vibration Sinusoidal
IEC 60255–21–1, Class 2 5 Hz to 8 Hz: ±7.5 mm Amplitude;
IEC 60068–2–6 8 Hz to 150 Hz: 2 g acceleration
Frequency sweep rate1 Octave/min
20 cycles in 3 orthogonal axes.
