Technical Data
10-37SJ62 Manual
C53000-G1140-C121-1
Alternative Voltage Voltage Supply via Integrated Converter
Bridging Time for Failure/Short Circuit ≥ 10 ms
10.1.3 Binary Inputs and Outputs
Binary Inputs Number
7SJ621*– 8 (configurable)
7SJ622*– 11 (configurable)
Nominal Voltage Range 24 VDC to 250 VDC, bipolar
Current Consumption, Energized approx. 1.8 mA, independent of the
control voltage
Switching Thresholds adjustable voltage range with jumpers
– For Nominal Voltages 24/48/60 VDC V
PU
≥ 19 VDC
V
DO
≤ 14 VDC
– For Nom. Voltages 110/125/220 VDC V
PU
≥ 88 VDC
V
DO
≤ 66 VDC
Maximum Permissible Voltage 300 V DC
Impulse Filter on Input 220 nF Coupling Capacitor at 220 V with
recovery time > 60 ms
Output Relays
1
) Output Relays for Commands/Annunciations
Number
7SJ621*– 8 (configurable)
7SJ622*– 6 (configurable)
Contacts per Relay 1 NO/form A
Switching Capability MAKE 1000W/VA
BREAK 30 W/VA
40 W resistive
25 W at L/R ≤ 50 ms
Switching Voltage 250 V
Permissible Current per Contact 5 A continuous
and Total Current on common path 30 A for 0.5 s
1 Live Status Alarm Relay
Contacts 1 changeover contact/form C
Switching Capability MAKE 30 W/VA
BREAK 20 W/VA
30 W resistive
25 W at L/R ≤ 50 ms
Nominal Power Supply Alternating Voltage
V
PS
AC
115 VAC 230 VAC
Permissible Voltage Ranges 92 to 132 VAC 184 to 265 VAC
Power Consumption, Quiescent approx. 3 VA approx. 3 VA
Power Consumption, Energized approx. 9 VA approx. 7 VA
