Functions
6-56 7SJ62 Manual
C53000-G1140-C121-1
6.3.2.3 Information List for Directional Phase Overcurrent Protection
F#
LCD-Text
Comment
2691 67/67N picked up 67/67N picked up
2696 67/67N TRIP 67/67N TRIP
2651 67/67-TOC OFF 67/67-TOC switched OFF
2652 67 BLOCKED 67/67-TOC is BLOCKED
2653 67 ACTIVE 67/67-TOC is ACTIVE
2642 67-2 picked up 67-2 picked up
2649 67-2 TRIP 67-2 TRIP
2660 67-1 picked up 67-1 picked up
2665 67-1 TRIP 67-1 TRIP
2670 67-TOC pickedup 67-TOC picked up
2675 67-TOC TRIP 67-TOC TRIP
2692 67 A picked up 67/67-TOC Phase A picked up
2693 67 B picked up 67/67-TOC Phase B picked up
2694 67 C picked up 67/67-TOC Phase C picked up
2647 67-2 Time Out 67-2 Time Out
2664 67-1 Time Out 67-1 Time Out
2674 67-TOC Time Out 67-TOC Time Out
2628 Phase A forward Phase A forward
2629 Phase B forward Phase B forward
2630 Phase C forward Phase C forward
2632 Phase A reverse Phase A reverse
2633 Phase B reverse Phase B reverse
2634 Phase C reverse Phase C reverse
2637 67-1 BLOCKED 67-1 is BLOCKED
2655 67-2 BLOCKED 67-2 is BLOCKED
2669 67-TOC BLOCKED 67-TOC is BLOCKED
2676 67-TOC DiskPU 67-TOC disk emulation is ACTIVE
2604 >BLK 67/67-TOC >BLOCK 67/67-TOC
2615 >BLOCK 67-2 >BLOCK 67-2
2621 >BLOCK 67-1 >BLOCK 67-1
2622 >BLOCK 67-TOC >BLOCK 67-TOC
