Technical Data
10-10 7SJ62 Manual
C53000-G1140-C121-1
• Do not withdraw or insert individual modules while the protective device is ener-
gized. When handling the modules or the device outside of the case, standards for
components sensitive to electrostatic discharge (ESD) must be observed. The mod-
ules and device are not endangered when inserted into the case.
10.1.9 Construction
Case 7XP20
Dimensions see dimensional drawings, Section 10.19
Weight (mass)
– In case for surface mounting 9.9 pounds (4.5 kg)
– In case for flush mounting 8.8 pounds (4.0 kg)
International Protection Under IEC 60529
– in the surface mounted case IP 51
– in the flush mounted case and in model
with the detached operator interface
Front IP 51
Back IP 50
– For human safety IP 2x Terminals covered with protection cap
