Functions
6-1737SJ62 Manual
C53000-G1140-C121-1
6.19.4.1 Settings for Auxiliary Functions
Demand and Min/
Max Measurement
Setup
Oscillographic
Fault Recording
Addr. LCD-Text Setting Options Default Setting Comments
8301 DMD Interval 15 Min., 1 Sub
15 Min., 3 Subs
15 Min., 15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min., 1 Sub Interval for Averaging
8302 DMD Sync. Time On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Synchronization time to form aver-
age values
8311 MinMax cycRESET NO
YES
YES Automatic cyclic reset function
8312 MiMa RESET TIME 0
~ 1439 min 0 min Min/Max reset timer (time of day)
8313 MiMa RESET CYCLE 1
~ 365 Days 7 Days Min/Max reset cycle period
8314 MinMaxRES.START 1 ~ 365 Days 1 Days Min/Max, Start reset cycle in ...
Addr. LCD-Text Setting Options Default Setting Comments
0401 WAVEFORMTRIGGER Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Trigger and Save Criterion for Oscillo-
graphic Records
0402 WAVEFORM DATA Fault event
Pow.Sys.Flt.
Fault event Recording scope (for automatic re-
closing)
0403 MAX . LENGTH 0.30
~ 5.00 sec. 1.00 sec. Maximum length of a record
0404 PRE. TRIG. TIME 0.05 ~ 0.50 sec. 0.10 sec. Pre-trigger time included in records
0405 POST REC. TIME 0.05
~ 0.50 sec. 0.10 sec. Time after dropout of save criterion
included in records
0406 BinIn CAPT.TIME 0.10
~ 5.00 sec. 0.50 sec. Record length for external trigger
