4.4 Control
The multiple application possibilities for SIPROTEC
®
4 devices require an equally
flexible concept for command editing and control.
Remote If the device is integrated into a control system, then command outputs can be remote-
ly controlled via the system interface using telegrams from
q SCADA or
q substation controller devices such as SICAM SC.
Local On-site, the SIPROTEC
®
4 device offers the possibility to control a circuit breaker or
primary switching equipment using the HMI.
For devices with a four-line display, control operations are carried out using:
• 0DLQPHQX → &RQWURO → %UHDNHU6ZLWFK → &RQWURO → Equipment and in-
tended direction 21 or 2)) (Figure 4-9), or
• The Function Keys F1 to F4.
The functionality of these keys is programmable using CFC. Their factory default func-
tion does not do any breaker control.
Figure 4-9 On-site Control Using the HMI
0$,10(18

0HDVXUHPHQW²!
!&RQWURO²!
&21752/

!%UHDNHU6ZLWFK²!
!7DJJLQJ²!
&21752/

!%UHDNHU6ZLWFK²!
!7DJJLQJ²!
%5($.(56:,7&+

!'LVSOD\²!
!&RQWURO²!
