Siemens SIPROTEC 7SJ62 - 2 Hardware and Connections

2-17SJ62 Manual
C53000-G1140-C121-1
Hardware and Connections 2
An overview of the hardware of the 7SJ62 and detailed information regarding connec-
tions to the device are provided in this section.
The options for panel mounting and cubicle mounting are described. Device construc-
tion is presented. The options for terminal connections and communication interfaces
are covered.
Data are given for wire connections and communication connections. Information on
accessories and tools is given.
2.1 Version of 7SJ62 for Panel Flush-Mounting / Cubicle Mounting 2-2
2.2 Version of 7SJ62 for Panel Surface-Mounting 2-14
