Siemens SIPROTEC 7SJ62 Instruction Manual

Functions
6-66 7SJ62 Manual
C53000-G1140-C121-1
Addr. Setting Setting Options Default Setting Comment Configuration
Definite Time Only IEC Curve ANSI Curve User Defined Pickup User def. Reset
1701 COLD LOAD
PICKUP
OFF
ON
OFF Dyn. Cold Load Setting Adj. On/Off X X X X X
1702 Start Condition No Current
Breaker Contact
No Current Dyn. Cold Load Setting Adj. Arming
Condition
XXXXX
1703 CB Open Time 0 ~21600 s 3600 s Dyn. Cold Load Setting Adj. Arming
Time
XXXXX
1704 Active Time 1 ~21600 s 3600 s Dyn. Cold Load Setting Adj. Active
Time
XXXXX
1705 Stop Time 1 ~600 s 600 s Dyn. Cold Load Setting Adj. Active
Time With Normal I
XXXXX
Addr. CLP–Setting Setting Options Default
Setting
Addr. Normal Setting Configuration
Definite Time Only IEC Curve ANSI Curve User Defined Pickup User def. Reset
1801 50c-2 PICKUP 0.50 ~ 175.00 A 50.00 A 1202 50-2 PICKUP X X X X X
1802 50c-2 DELAY 0.00 ~ 60.00 sec. 0.00 sec. 1203 50-2 DELAY X X X X X
1803 50c-1 PICKUP 0.50 ~ 175.00 A 10.00 A 1204 50-1 PICKUP X X X X X
1804 50c-1 DELAY 0.00 ~ 60.00 sec. 0.30 sec. 1205 50-1 DELAY X X X X X
1805 51c PICKUP 0.50 ~ 20.00 A 7.50 A 1207 51 PICKUP X X X X
1806 51c TIME DIAL 0.05 ~ 3.20 sec. 0.50 sec. 1208 51 TIME DIAL, IEC X X X
1807 51c TIME DIAL 0.5 ~ 15.00 5.00 sec. 1209 51 TIME DIAL, ANSI X
Addr. Setting Setting Options Default
Setting
Addr. Normal Setting Configuration
Definite Time Only IEC Curve ANSI Curve User Defined Pickup User def. Reset
1901 50Nc-2 PICKUP 0.25 ~ 175.00 A 35.00 A 1302 50N-2 PICKUP X X X X X
1902 50Nc-2 DELAY 0.00 ~ 60.00 sec. 0.00 sec. 1303 50N-2 DELAY X X X X X
1903 50Nc-1 PICKUP 0.25 ~ 175.00 A 7.50 A 1304 50N-1 PICKUP X X X X X
1904 50Nc-1 DELAY 0.00 ~ 60.00 sec. 0.30 sec. 1305 50N-1 DELAY X X X X X
