Functions
6-84 7SJ62 Manual
C53000-G1140-C121-1
1
) if address 0213: Vab, Vbc, VGnd
2
) if address 0213: Van, Vbn, Vcn
3106 VPH MIN 10 ~ 100 V 40 V Voltage of faulty phase Vph min X X
3107 VPH MAX 10 ~ 100 V 75 V Voltage of
Unfaulted phase
Vph max
XX
3109
64-1 VGND
1
)
1.8 ~ 130.0 V 40.0 V
64-1 Ground Displacement Voltage X X
3110
64-1 VGND
2
)
10.0 ~ 225.0 V 70.0 V
64-1 Ground Displacement Voltage X X
3111 T-DELAY
Pickup.
0.4 ~ 320.00 sec 1.00 sec
Time-DELAY Pickup X X
3112
64-1 DELAY
0.10 ~ 40000.0 sec 10.00 sec
64-1 Time Delay X X
3113
50Ns-2 PICKUP
0.003 ~ 1.500 A 0.300 A
50Ns-2 Pickup X X
3114
50Ns-2 DELAY
0.00 ~ 320.00 sec 1.00 sec
50Ns-2 Time Delay X X
3115
67Ns-2 DIRECT.
Forward
Reverse
Non-Directional
Forward
67Ns-2 Direction X X
3117
50Ns-1 PICKUP
0.003 ~ 1.500 A 0.100 A
50Ns-1 Pickup X
3118
50Ns-1 DELAY
0.00 ~ 320.00 sec 2.00 sec
50Ns-1 Time delay X
3119
51Ns PICKUP
0.003 ~ 1.400 A 0.100 A
51Ns Pickup X
3120
51Ns TIME DIAL
0.10 ~ 4.00 sec 1.00 sec
51Ns Time Dial X
3122
67Ns-1 DIRECT. Forward
Reverse
Non-Directional
Forward 67Ns-1 Direction X X
3123
RELEASE
DIRECT.
0.003..1.200 A 0.010 A Release directional element X X
3124
PHI CORREC-
TION
-45.0..45.0 ° 0.0 ° Correction Angle for Dir. Determina-
tion
XX
3125
MEAS. METHOD COS Phi
SIN phi
COS Phi Measurement method for Direction X X
3126
RESET DELAY 0..60 sec 1 sec Reset Delay X X
3130
PU CRITERIA Vgnd OR INs
Vgnd AND INs
Vgnd OR INs Sensitive Ground Fault PICKUP crite-
ria
XX
3131
M.of PU TD Multiples of PU Time-Dial X
Addr. LCD-Text Setting options Default Setting Comment Configu-
ration
Definite Time only User Defined Pickup
