= 1 A, divide the Setting Options values and Default Setting values by 5. Consider the
current transformer ratios when setting the device with primary values.
Addr. LCD-Text Setting Options Default Setting Comments Configu-
ration
Definite Time only ANSI Curve IEC Curve
4001 FCT 46 ON
OFF
OFF Negative sequence current
protection
XXX
4002 46-1 PICKUP 0.50 ~ 15.00 A 0.50 A Pickup current 46-1 X X X
4003 46-1 DELAY 0.00 ~ 60.00 sec 1.50 sec Definite delay time 46-1 X X X
4004 46-2 PICKUP 0.50 ~ 15.00 A 2.50 A Pickup current 46-2 X X X
4005 46-2 DELAY 0.00 ~ 60.00 sec 1.50 sec Definite delay time 46-2 X X X
4006 46 IEC CURVE Normal Inverse
Very Inverse
Extremely Inverse
Extremely Inv. Current-time IEC
characteristic curve 46-
TOC
X
X
X
4007 46 ANSI CURVE Extremely Inverse
Inverse
Moderately Inverse
Very Inverse
Extremely Inv. Current-time ANSI
characteristic curve 46-
TOC
X
X
X
X
4008 46-TOC PICKUP 0.50 ~ 10.00 A 4.50 A Pickup current 46-TOC X X
4009 46-TOC TIMEDIAL 0.50 ~ 15.00 sec 5.00 sec Time dial, ANSI
characteristics, 46-TOC
X
4010 46-TOC TIMEDIAL 0.05 ~ 3.20 sec 0.50 sec Time multiplier, IEC
characteristics, 46-TOC
X
4011 46-TOC RESET Instantaneous
Disk Emulation
Instantaneous Reset characteristic for 46-
TOC, ANSI current-time
characteristics
X
