Siemens SIPROTEC 7SJ62 Instruction Manual

Functions
6-138 7SJ62 Manual
C53000-G1140-C121-1
7103 BLK MAN. CLOSE NO
YES
NO Block automatic reclosing dur-
ing manual closing of breaker
(01 - BI)
XXX
7105 TIME RESTRAINT 0.50
~ 320.00 sec. 3.00 sec. Reset time of automatic reclos-
ing
XXX
7108 SAFETY 79 ready 0.01
~ 300.00 sec. 15.00 sec. Safety time until automatic re-
closing is ready
XXX
7113 CHECK CB? No check
Chk each cycle
No check Check breaker position indica-
tion before attempting a reclos-
ing shot
XX-
7115 CB TIME OUT 0.10
~ 320.00 sec. 3.00 sec. Breaker ready monitoring time X X -
7116 MAX.InhibitTIME 0.01 ~ 320.00 sec. 15.00 sec. Maximum inhibit time of auto re-
closing allowed for external bi-
nary input
-XX
7127 DEADTIME 1: PH 0.01
~ 320.00 sec. 0.50 sec. Dead Time 1, Phase Fault X X X
7128 DEADTIME 1: G 0.01
~ 320.00 sec. 0.50 sec. Dead Time 1, Ground Fault X X X
7129 DEADTIME 2: PH 0.01
~ 320.00 sec. 0.50 sec. Dead Time 2, Phase Fault X X X
7130 DEADTIME 2: G 0.01 ~ 320.00 sec. 0.50 sec. Dead Time 2, Ground Fault X X X
7131 DEADTIME 3: PH 0.01
~ 320.00 sec. 0.50 sec. Dead Time 3, Phase Fault X X X
7132 DEADTIME 3: G 0.01
~ 320.00 sec. 0.50 sec. Dead Time 3, Ground Fault X X X
7133 DEADTIME 4: PH 0.01 ~ 320.00 sec. 0.50 sec. Dead Time 4-9, Phase Fault X X X
7134 DEADTIME 4: G 0.01
~ 320.00 sec. 0.50 sec. Dead Time 4-9, Ground Fault X X X
7135 # OF RECL. GND 0
~ 9 1 Number of reclosing attempts
for ground faults
XXX
7136 # OF RECL. PH 0
~ 9 1 Number of reclosing attempts
for phase faults
XXX
7140 ZONE SEQ.CO-
ORD.
OFF
ON
OFF Zone sequence coordination - X X
7150 50–1/50N–1 No influence
Starts 79
Stops 79
No influence 50–1 and 50N–1 supervision of
automatic reclosing
XXX
7151 50–2/50N–2 No influence
Starts 79
Stops 79
No influence 50–2 and 50N–2 supervision of
automatic reclosing
XXX
7152 51/51N No influence
Starts 79
Stops 79
No influence 51 and 51N supervision of auto-
matic reclosing
XXX
7153 67–1/67N–1 No influence
Starts 79
Stops 79
No influence 67–1 and 67N–1 supervision of
automatic reclosing
XXX
7154 67–2/67N–2 No influence
Starts 79
Stops 79
No influence 67–2 and 67N–2 supervision of
automatic reclosing
XXX
Addr. LCD-Text Setting Options Default Setting Comments Ordering Code
7SJ62**–
**A**–
**M**–
**B**– **N**– **C**–
**P**–
