Siemens SIPROTEC 7SJ62 Instruction Manual

Functions
6-140 7SJ62 Manual
C53000-G1140-C121-1
7155 67–TOC/67N–
TOC
No influence
Starts 79
Stops 79
No influence 67–TOC and 67N–TOC supervi-
sion of automatic reclosing
XXX
7156 sens Ground Flt No influence
Starts 79
Stops 79
No influence Sensitive ground fault detection
supervision of automatic reclos-
ing
XXX
7157 46 No influence
Starts 79
Stops 79
No influence 46–1, 46–2, and 46N–TOC su-
pervision of automatic reclosing
(one setting)
XXX
7158 BINARY INPUT No influence
Starts 79
Stops 79
No influence Binary input supervision of auto-
matic reclosing (phase and
ground)
XXX
7159 3Pol.PICKUP BLK YES
NO
NO 3 pole trips block automatic re-
closing
XXX
7170 1.Cy: 50(N)–1 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–1 and 50N–1 during first
shot
XXX
7171 1.Cy: 50(N)–2 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–2 and 50N–2 during first
shot
XXX
7172 1.Cy: 67(N)–1 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
67–1 and 67N–1 during first
shot
XXX
7173 1.Cy: 67(N)–2 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
67–2 and 67N–2 during first
shot
XXX
7174 2.Cy: 50(N)–1 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–1 and 50N–1 during second
shot
XXX
7175 2.Cy: 50(N)–2 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–2 and 50N–2 during second
shot
XXX
7176 2.Cy: 67(N)–1 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
67–1 and 67N–1 during second
shot
XXX
7177 2.Cy: 67(N)–2 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
67–2 and 67N–2 during second
shot
XXX
7178 3.Cy: 50(N)–1 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–1 and 50N–1 during third
shot
XXX
7179 3.Cy: 50(N)–2 Not Blocked
Blocked Via 79
Not Blocked Automatic reclosing control of
50–2 and 50N–2 during third
shot
XXX
Addr. LCD-Text Setting Options Default Setting Comments Ordering Code
7SJ62**–
**A**–
**M**–
**B**– **N**– **C**–
**P**–
