Operators Tools
7-237SJ62 Manual
C53000-G1140-C121-1
Figure 7-26 Setting Limit Values at the Front Panel — Example
To change a limit value, mark the specific value using the and keys, and then
press the key.
A request for Password No. 5 (for settings parameters) is given. After password entry
and confirmation with the key, the previous value appears in a box with a flashing
cursor. Overwrite the previous value with the desired new value using the number
keys. If the entered value is outside the allowable value range, then the maximum or
minimum limit value appears at the bottom of the display.
Press the key. The new value appears in the list of limit values.
Other limit values can be changed in the same manner.
Upon leaving this level using the or keys, the safety inquiry “$UH\RXVXUH"”
appears, with the default answer “<HV” (Figure 7-26). Confirm with the key if the
value should become effective. If a change to the value is not desired, press the
key so that the answer “1R” is marked, and confirm this with the key. To correct
the value, mark “(VFDSH”, confirm this with the key, and enter the value again
From PC with
DIGSI
®
4
The metered value groups are found under 0HDVXUHPHQW (Figure 7-2) with a double
click. Select 2WKHU and then 6HW3RLQWV0HDVXUHG9DOXHV.
Note:
Set points are only in online–mode available!
By double clicking on an entry in the list view in the right side of the window, the limit
values are loaded. Mark the number of the value that is to be changed. With the
right
mouse button, open the context menu and click on 6HW, as shown in Figure 7-27. A
password inquiry (password for individual settings) occurs. Next, the dialog field 6HW
0HWHUHG9DOXH is opened. Enter the desired value in the entry field. Then click on
2..
The entered value is transferred to the device and the display within the window in Fig-
ure 7-27 is updated.
0($685(0(17
!6HW3RLQWV09
!5HVHW
Etc.
ENTER
6(732,17609
!
,$GPG!
ENTER
3:6HWWLQJV"
Enter Password No. 5 (individual settings)
and confirm with
ENTER
,/
ENTER
$UH<RX6XUH"
!<(612(VFDSH
ENTER
ENTER
ENTER
MENU
ENTER
ENTER
ENTER
:
