Operators Tools
7-34 7SJ62 Manual
C53000-G1140-C121-1
Control of the setting groups can always be regained by changeover to one of the
Groups A through D.
The key can be used to return to the 6(77,1*6 sub-menu; the key can be
pressed to returns to the 0$,10(18.
From PC with
DIGSI
®
4
By opening the 2QOLQH directory with a double click in DIGSI
®
4, the operating func-
tions for the device appear in the left part of the window. See Figure 7-38.
Figure 7-38 Function Selection Window in DIGSI
®
4
Double click on 6HWWLQJV to find &KDQJH*URXS in the data window (Figure 7-38
right).
Double click on &KDQJH*URXS. The &KDQJH*URXS window is opened, as shown
in Figure 7-39.
