Siemens SIPROTEC 7SJ62 Instruction Manual

Installation and Commissioning
8-117SJ62 Manual
C53000-G1140-C121-1
1
) Factory settings for devices with power supply voltages of 24 VDC to 125 VDC.
2
) Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115/
230 VAC.
1
) Factory settings for devices with power supply voltages of 24 VDC to 125 VDC.
2
) Factory settings for devices with power supply voltages of 110 VDC to 220 VDC and 115/
230 VAC.
Table 8-2 Jumper Settings for the Nominal Voltage of the Integrated Power Supply on the
CPU Board
Jumper Nominal Voltage
60/110/125 VDC 110/125/220/250 VDC
115 VAC
24/48 VDC
230 VAC
X51 1-2 2-3
Jumpers X51
through X54 are
not used
X52 1-2 and 3-4 2-3
X53 1-2 2-3
X54 1-2 2-3
Can be interchanged Not changeable
Table 8-3 Jumper Settings for the Pickup Voltages of the Binary Inputs BI1 through BI3
on the CPU Board
Binary Input Jumper 17 VDC
Pickup
1
)
73 VDC Pickup
2
)
BI1 X21 L H
BI2 X22 L H
BI3 X23 L H
Table 8-4
Factory jumper settings for the Pickup Voltages of the binary inputs BI4
through BI11 on the I/O board
Binary Input Jumper 17 VDC
Pickup
1
)
73 VDC Pickup
2
)
BI4 X21 L H
BI5 X22 L H
BI6 X23 L H
BI7 X24 L H
BI8 X25 L H
BI9 X26 L H
BI10 X27 L H
BI11 X28 L H
