Appendix
A-317SJ62 Manual
C53000-G1140-C121-1
51 Device is Operational and Protecting
(Device OK)
OUT O/O LED REL O/O GI 135 81 1 GI
52 At Least 1 Protection Funct. is Active
(ProtActive)
IntSP O/O LED REL O/O GI 160 18 1 GI
55 Reset Device (Reset Device) OUT O LED REL O/O GI
56 Initial Start of Device (Initial Start) OUT O LED REL O/O GI 160 5 1
60 Reset LED (Reset LED) OUT O LED REL O/O GI 160 19 1
67 Resume (Resume) OUT O LED REL OM FM O/O GI
68 Clock Synchronization Error (Clock Syn-
cError)
OUT O/O LED REL O/O GI
69 Daylight Saving Time (DayLightSav-
Time)
OUT O/O LED REL O/O GI
110 Event lost (Event Lost) OUT O LED REL O/O GI 135 130 1
113 Flag Lost (Flag Lost) OUT O M LED REL O/O GI 135 136 1 GI
125 Chatter ON (Chatter ON) OUT O/O LED REL O/O GI 135 145 1 GI
140 Error with a summary alarm (Error Sum
Alarm)
OUT O/O LED REL O/O GI 160 47 1 GI
160 Alarm Summary Event (Alarm Sum
Event)
OUT O/O LED REL O/O GI 160 46 1 GI
178 I/O-Board Error (I/O-Board error) OUT O/O LED REL O/O GI
144 Error 5V (Error 5V) OUT O/O LED REL O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
