Appendix
A-437SJ62 Manual
C53000-G1140-C121-1
1994 Cold-Load-Pickup switched OFF (CLP
OFF)
OUT O/O LED REL O/O GI 60 244 1 GI
1995 Cold-Load-Pickup is BLOCKED (CLP
BLOCKED)
OUT O/O O/O LED REL O/O GI 60 245 1 GI
1996 Cold-Load-Pickup is RUNNING (CLP
running)
OUT O/O LED REL O/O GI 60 246 1 GI
1997 Dynamic settings are ACTIVE (Dyn set.
ACTIVE)
OUT O/O LED REL O/O GI 60 247 1 GI
6503 >BLOCK 27 undervoltage protection
(>BLOCK 27)
SP LED BI REL O/O GI 74 3 1 GI
6505 >27-Switch current supervision ON (>27
I SUPRVSN)
SP O/O LED BI REL O/O GI 74 5 1 GI
6506 >BLOCK 27-1 Undervoltage protection
(>BLOCK 27-1)
SP O/O LED BI REL O/O GI 74 6 1 GI
6508 >BLOCK 27-2 Undervoltage protection
(>BLOCK 27-2)
SP O/O LED BI REL O/O GI 74 8 1 GI
6530 27 Undervoltage protection switched
OFF (27 OFF)
OUT O/O LED REL O/O GI 74 30 1 GI
6531 27 Undervoltage protection is BLOK-
KED (27 BLOCKED)
OUT O/O O/O LED REL O/O GI 74 31 1 GI
6532 27 Undervoltage protection is ACTIVE
(27 ACTIVE)
OUT O/O LED REL O/O GI 74 32 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
