Appendix
A-617SJ62 Manual
C53000-G1140-C121-1
859 Va-n Min (Va-nMin=) MVT O/O GI
860 Va-n Max (Va-nMax=) MVT O/O GI
861 Vb-n Min (Vb-nMin=) MVT O/O GI
862 Vb-n Max (Vb-nMax=) MVT O/O GI
863 Vc-n Min (Vc-nMin=) MVT O/O GI
864 Vc-n Max (Vc-nMax=) MVT O/O GI
865 Va-b Min (Va-bMin=) MVT O/O GI
867 Va-b Max (Va-bMax=) MVT O/O GI
868 Vb-c Min (Vb-cMin=) MVT O/O GI
869 Vb-c Max (Vb-cMax=) MVT O/O GI
870 Vc-a Min (Vc-aMin=) MVT O/O GI
871 Vc-a Max (Vc-aMax=) MVT O/O GI
872 V neutral Min (Vn Min =) MVT O/O GI
873 V neutral Max (Vn Max =) MVT O/O GI
874 V1 (positive sequence) Voltage Mini-
mum (V1 Min =)
MVT O/O GI
875 V1 (positive sequence) Voltage Maxi-
mum (V1 Max =)
MVT O/O GI
876 Active Power Minimum (Pmin=) MVT O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
