A-637SJ62 Manual
C53000-G1140-C121-1
I C dmd> (I Cdmd>) LV O/O
I1dmd> (I1dmd>) LV O/O
273 Set Point Phase A dmd> (SP. I A dmd>) OUT O/O LED REL OM O/O GI 135 230 1 GI
274 Set Point Phase B dmd> (SP. I B dmd>) OUT O/O LED REL OM O/O GI 135 234 1 GI
275 Set Point Phase C dmd> (SP. I C dmd>) OUT O/O LED REL OM O/O GI 135 235 1 GI
276 Set Point positive sequence I1dmd>
(SP. I1dmd>)
OUT O/O LED REL OM O/O GI 135 236 1 GI
|Pdmd|> (|Pdmd|>) LV O/O
|Qdmd|> (|Qdmd|>) LV O/O
|Sdmd|> (|Sdmd|>) LV O/O
277 Set Point |Pdmd|> (SP. |Pdmd|>) OUT O/O LED REL OM O/O GI 135 237 1 GI
278 Set Point |Qdmd|> (SP. |Qdmd|>) OUT O/O LED REL OM O/O GI 135 238 1 GI
279 Set Point |Sdmd|> (SP. |Sdmd|>) OUT O/O LED REL OM O/O GI 135 239 1 GI
284 Set Point 37-1 Undercurrent alarm (SP.
37-1 alarm)
OUT O/O LED REL OM O/O GI 135 244 1 GI
37-1 under current (37-1) LV O/O
|Power Factor|< (|PF|<) LV O/O
285 Set Point 55 Power factor alarm (SP.
PF(55)alarm)
OUT O/O LED REL OM O/O GI 135 245 1 GI
Reset meter (Meter res) IntSP_Ev O BI O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
