SIPROTEC 4 Devices
4-32 7SJ62 Manual
C53000-G1140-C121-1
To set the framing and baud rate:
• Double click on 6HULDO3RUWV in the data window and enter the specific settings
in the window that follows.
Figure 4-28 DIGSI
®
4, Interface Settings Window
Readout in the
HMI
The interface settings can be checked using the SIPROTEC
®
4 device HMI.
In the main menu, select 6HWWLQJV → 6HWXS([WUDV → 6HULDO3RUWV → follow-
ing menus.
Figure 4-29 Readout of Serial Interface Settings from the HMI, example
6(5,$/32576

)URQW3RUW²!
6\VWHP3RUW²!
6HUYLFH3RUW²!
6(783(;75$6

'DWH7LPH²!
&ORFN6HWXS²!
6HULDO3RUWV²!
'HYLFH²,'²!
0/)%9HUVLRQ²!
&RQWUDVW²!
Note:
The interface for connecting a time control device is described in the Sub-section 4.14,
Time Synchronization.
