Configuration in STEP 7
5.7 Configuring TIM modules
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
117
-specific parameters are entered in the "Properties" dialogs for network
and network node parameter
assignment. These are explained in the relevant sections.
"General" tab
General tab
The "General" tab informs you about the general properties of a TIM module.
Figure 5-24 "Properties - TIM" dialog, "General" tab
This tab contains the following output boxes and parameter assignment options:
● "Short Designation:" output box the module type and a brief description are displayed.
● The "Order No." output box displays the article number of the module.
