Siemens TIM 4R-IE DNP3 - Inserting and Copying Objects and Channels

The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
185
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group
[variation]
(S7 data type)
DNP3 level *
Use in stations
type **
4 ... 48
• 30 [2] (BYTE)
• 32 [2] (BYTE)
• 32 [4] (BYTE)
• 41 [2] (BYTE)
• 110 [1..255] (CHAR)
• 111 [1..255] (CHAR)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• 1 ... 5
• 1 ... 5
• S
• S
• S
• M
• M / S
• S
Dat12D_R
Data object for receive direction
Receive max. 12 double words
(at least 1 double word) with
any information
1 ... 12
• 30 [1] (DINT)
• 30 [5] (REAL)
• 32 [1] (DINT)
• 32 [3] (DINT)
• 32 [7] (REAL)
• 40 [1] (DINT)
• 40 [3] (REAL)
• 41 [1] (DINT)
• 41 [3] (REAL)
• 1 ... 5
• 5
• 1 ... 3
• 4 ... 5
• 5
• 1 ... 5
• 5
• 1 ... 5
• 5
• M
• M
• M
• M
• M
• S
• S
• S
• S
2 ... 24
• 30 [2] (INT, WORD)
• 32 [2] (INT, WORD)
• 32 [4] (INT, WORD)
• 40 [2] (INT, WORD)
• 41 [2] (INT, WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• 1 ... 5
• M
• M
• M
• S
• S
4 ... 48
• 30 [2] (BYTE)
• 32 [2] (BYTE)
• 32 [4] (BYTE)
• 40 [2] (BYTE)
• 41 [2] (BYTE)
• 110 [1..255] (CHAR)
• 111 [1..255] (CHAR)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• 1 ... 5
• 1 ... 5
• 1 ... 5
• M
• M
• M
• S
• S
• M / S
• M
Objects for data exchange with MODBUS slaves (only in station)
ModbusWrite
Write data from the station
CPU to the MODBUS slave
-
-
ModbusRead
Read data from the MODBUS
slave to the station CPU
-
-
