Siemens TIM 4R-IE DNP3 - The Properties of Subscriber Dialog; Parameter Overview

The SINAUT Configuration Tool
6.5 The Subscriber Administration
TIM DNP3
152 System Manual, 06/2014, C79000-G8976-C253-03
● Subscriber information: Which subscribers exist?
● Networking information: Who communicates with whom over which connections?
● DB configuration information: Which data blocks are generated for a CPU?
Configuring TD7 software
The last entry in the navigation to the left in the window contains the subscribers with
TD7onTIM. With these subscribers, the properties of the TD7 software are configured
directly on the TIM.
The parameter assignment for this data is described in the section TD7onTIM (Page 161).
Printing subscriber lists
To provide users with an overview of the existing subscribers, the SINAUT configuration tool
provides the option of printing out the list of subscribers in a brief overview format and as a
long version.
A print preview function is available to check the output before printing.
6.5.2
Subscriber list
Information in the subscriber list
The window of the subscriber administration contains the following areas:
● Directory tree in the left-hand part of subscriber administration
● Subscriber list top right
● Parameter area below the subscriber list
