Uses and properties of the TIM
1.6 Other properties of the TIM
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
23
●
TIM 3V-IE DNP3
46635650 (http://support.automation.siemens.com/WW/view/en/46635650)
●
TIM 4R-IE DNP3
46636298 (http://support.automation.siemens.com/WW/view/en/46636298)
1.6
Other properties of the TIM
Compatible SIMATIC families
The following table shows the SIMATIC families in which the two TIM variants can be used.
Can be used in SIMATIC family:
S7-300
S7-400
TIM 3V-IE DNP3
•
no
TIM 4R-IE DNP3
•
•
Interfaces
The table below shows the number of interfaces of the two TIM variants.
Ethernet RJ-45 port
Serial interface for an
external modem or for
connecting MODBUS slaves
TIM 3V-IE DNP3 1 1
(RS232)
TIM 4R-IE DNP3 2 2
(RS232/RS485)
