Siemens TIM 4R-IE DNP3 - Configurations with S7-400 H

Network structures and configurations
2.4 Configuration options with the DNP3 TIMs
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
45
Figure 2-2 Configurations with S7-400
2.4.3
Configurations with S7-400H
Possible configurations
The following configuration options are possible with DNP3 TIMs in the S7-400H. You will
find the numbering of the station connectors in the following figure.
1. Single connection of a station via 1 Ethernet network
2. Single connection of a station via 1 DNP3 dedicated line or dial-up network
3. Redundant connection of a station via 1 DNP3 dedicated line or dial-up network and 1
Ethernet network
4. Redundant connection of a station via 2 DNP3 dedicated line or dial-up networks (or
mixed)
