Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
296 System Manual, 06/2014, C79000-G8976-C253-03
F560 0417 Unknown DNP3 subscriber address
received
DNP3 master station sends unknown address. The
received master station and station address are
F560 0418 Command rejected A command of the DNP3 master station could not be
executed. Object group, variation and type of the
F560 0419 Command not supported An unknown or unsupported command of the DNP3
master station was received. Object group, variation and
type of the command are displayed.
F560 0420 Installation abort - DNP3 stack has
detected an inconsistent parameter
Configuration error
F560 0421 Message incoming: CPU of the station
<
DNP3 address
> (subscriber number)
in STOP mode
Message outgoing: CPU of the station
<
DNP3 address
> (subscriber number)
Note: The message is formed by a DNP3 master TIM
when it receives the set internal indication bit "IIN1.6" of
the station.
F560 0422 Message incoming: Messagequeue
Mesa full – image method active
Message outgoing: Messagequeue
Mesa no longer full – image method
inactive
With an incoming message: Due to bottlenecks in the
message transmission, there is a changeover from the
send buffer method to the image method. Values of data
points configured as an event are not written to the send
buffer but to the image. If the status remains, the
firmware nevertheless attempts to enter intermediate
values of the data points configured as an event in the
send buffer.
With an outgoing message: There is a changeover back
to the send buffer method.
MODBUS-specific diagnostics messages of the TIM
Diagnostics messages
Below you will find a list of the MODBUS-specific diagnostics messages sorted according to
the detailed event:
Modbus gateway installation error
Modbus gateway installation successful
F560 0804 Error when reading or writing to a
