Siemens TIM 4R-IE DNP3 - MODBUS-Specific Diagnostics Messages of the TIM

Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
295
7.3.6.3
DNP3-specific diagnostics messages of the TIM
Diagnostic messages
Below you will find a list of the DNP3-specific diagnostics messages sorted according to the
detailed event:
Event ID
(hex)
Detailed
event
(hex)
Status message
Meaning
F560 0400 No TD7onTIM configuration exists TD7onTIM configuration data was not transferred to the
module.
F560
0401
Memory error
The available RAM memory on the module is exhausted.
F560
0402
Error receiving message
Internal error
F560 0403 Amount of diagnostics data to high
(> 32 767). Diagnostics data of the
event buffer cannot be transferred
Diagnostics data relating to message management could
not be transferred to the diagnostics tool.
F560
0404
Unknown ORG PDU received
Internal error
F560
0405
DNP3 data output locked
No DNP3 communication possible
F360
0405
DNP3 data output released
DNP3 communication possible
F560
0406
Unknown control message
Internal error
F560
0407
Error releasing memory
The available RAM memory on the module is exhausted.
F560 0408 Time-of-day function not available Time-of-day synchronization by DNP3 master station not
possible
F560
0409
WAN SDB cannot be interpreted
Inconsistent system data block
F560
040A
Error creating a task
Internal error
F560
040B
WAN driver successfully installed.
DNP3 driver loaded
F960
040C
Modem does not set CTS signal
CTS control signal on the serial interface inactive
F860 040C Modem sets CTS signal again CTS control signal on the serial interface active
F560 040D WAN interface disrupted Serial communication disrupted. Bad data frame, for
example due to incorrect baud rate or invalid parity.
F460
040D
WAN interface OK
Serial communication is OK again.
F560
040E
WAN driver ready for communication
WAN driver ready
F560
040F
Time synchronization received
DNP3 master station has synchronized system time.
F560 0410
Unsolicited event transmission activated
or deactivated
Request to activate of deactivate unsolicited messages
F560
0411
IP connection established
Connection to DNP3 master station was established.
F360
0411
IP connection terminated
Connection to DNP3 master station was terminated.
F560
0412
Inconsistent routing table
Inconsistent configuration
F360
0413
DNP3 connection disrupted
Connection to specified master station disrupted
F260
0413
DNP3 connection established
Connection to specified master station established
F560 0414 Size of the process image of the inputs Highest DNP3 indexes of the input values (received from
DNP3 master station) are output.
F560 0415 Size of the process image of the
outputs
Highest DNP3 indexes of the output values (sent to
DNP3 master station) are output.
F560
0416
TD7 data cannot be interpreted
Internal error
