Siemens TIM 4R-IE DNP3 - Technical Specifications of the TIM 4 R-IE DNP3

TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
301
Technical specifications
8
8.1
Technical specifications of the TIM 3V-IE DNP3
Table 8- 1 Technical specifications of the TIM 3V-IE DNP3
Technical specifications of the TIM 3V-IE DNP3
Article number
6NH7803-3BA00-0AA0
Connection to WAN classic
Number
1
Execution
Serial port, 9-pin D-sub male connector
Standard
RS-232
Maximum permitted cable length
6 m
Transmission speed
9 600 ... 38 400 bps
Connection to LAN or IP-based WAN (Industrial Ethernet)
Number
1
Execution
RJ-45 jack
Properties 10/100BASE-T, IEEE 802, half duplex/full duplex, autocrossover, autonegotiation,
autosensing
Maximum permitted cable length
10 m
Transmission speed
10 / 100 Mbps
Permitted cable lengths (Ethernet) - (Alternative combinations per length range) *
0 ... 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 ... 85 m
• Max. 85 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable with
IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable +
10 m TP Cord via IE FC RJ45 Outlet
0 ... 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Electrical data
External power supply Supply voltage 24 VDC
Permitted range
min. 20.4 V, max. 28.8 V
Execution
2-pin plug-in terminal strip
Current consumption From 24 VDC, typical 160 mA
From 24 VDC, maximum
200 mA
From backplane bus
200 mA
Power loss at 24 VDC
Typical
5.8 W
