Technical specifications
8.1 Technical specifications of the TIM 3V-IE DNP3
TIM DNP3
300 System Manual, 12/2015, C79000-G8976-C253-04
Technical specifications of the TIM 3V-IE DNP3
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 ℃ to +60 ℃
During operation with the rack in-
stalled vertically
0 ℃ to +40 ℃
During storage
-40 ℃ to +70 ℃
During transportation
-40 ℃ to +70 ℃
Relative humidity
During operation
≤ 95 % at 25 °C, no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 60 °C
ambient temperature
Contaminant concentration
Acc. to ISA-S71.04 severity level G1, G2, G3
Design, dimensions and weight
Module format
Compact module for S7-300, single width
Degree of protection
IP20
Weight
250 g
Dimensions (W x H x D)
40 x 125 x 120 mm
Installation options
• Installation on a DIN rail
• Installation on an S7-300 standard rail
• Wall mounting
• Mounting in a 19" rack
• Switch panel
Product functions *
Configuration
Software for PG
SINAUT configuration software for PG
Storage of TIM configuration data
• on internal TIM flash memory
• on MMC of the S7-300-CPU
TIM can be operated in the role
• Station
• Node station
• Master station
• yes
• yes
• yes
No. of TIM 3V-IE DNP3 modules per
S7-300
1
Local communication Via backplane bus with the S7-300
CPU
possible using TD7onTIM
Via backplane bus with other TIMs in
the rack
Not possible
Via MPI interface of the S7-300 CPU
with other CPUs, TIMs, and/or PCs
Not possible
Work memory required on the S7
CPU
TD7onTIM software Best case, 0 bytes
Data memory on the TIM
Battery backed
no
Transmission protocol RS-232
Selectable protocols
DNP3
Asynchronous character format
(DNP3)
10 bits
Hamming distance d (DNP3)
2
