Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
294 System Manual, 06/2014, C79000-G8976-C253-03
Event ID
(hex)
Detailed
event
(hex)
Meaning
F560
076C
Invalid start index in received data message.
F560
076D
TD7-Run: Received data too large for destination object.
F560 076E TD7-Run: Start index of received data message does not match the receive channel of the
destination object.
F560
0773
TD7-Run: Object without partner or channels.
F560
0774
TD7-Run: No destination object found.
Diagnostic messages and activation of the group error LED
If an error occurs during startup, the read group LED (SF) of the TIM lights up and a
message to this effect is entered in the diagnostic buffer of the TIM.
If the TIM is installed as a CP in an S7-300 rack, a diagnostic interrupt is sent to the CPU.
The following table contains a summary of all error messages that caused the group error
LED (SF) to light up.
Table 7- 5 Classification of the messages and activation of the group error LED
Error class
Detailed event (hex) in the diagnostics message
Internal error 0061
0063, 0064, 0065, 0066, 0067
0069
0078, 0079, 0080
0083
06B0
External error
0320
No parameter assignment 0070
0071
0620
Bad parameter assignment 0077
0081
0110
0112
0300
031C
0500
0620
RAM error 0085
0086
