Uses and properties of the TIM
1.5 DNP3 device attributes of the TIM
TIM DNP3
22 System Manual, 06/2014, C79000-G8976-C253-03
Attribute
Meaning
Return value of the DNP3 TIM
220
Max. index of the analog outputs
According to the configuration
221
Number of analog outputs
Max. index +1
222
Support of binary output events
Not supported (negative acknowledgment)
223
Max. index of the binary outputs
According to the configuration
224
Number of binary outputs
Max. index +1
225
Support of frozen counter events
Is supported
226
Support of frozen counters
Is supported
227
Support of counter events
Is supported
228
Max. index of the counters
According to the configuration
229
Number of counters
Max. index +1
230
Support of frozen analog inputs
Not supported (negative acknowledgment)
231
Support of analog inputs
Is supported
232
Max. index of the analog inputs
According to the configuration
233
Number of analog inputs
Max. index +1
234
Support of double bit inputs
Not supported (negative acknowledgment)
235
Max. index of double bit inputs
0
236 Number of double bit inputs 0
237
Support of event messages with binary inputs
Is supported
238 Max. index of the binary inputs According to the configuration
239
Number of binary inputs
Max. index +1
240 Max. size of the application layer fragments in send
direction (station → master station)
2048 bytes
241 Max. size of the application layer fragments in
receive direction (master station → station)
2048 bytes
242
TIM software version
Software version
243
TIM hardware version
Hardware version
244
Not defined in the protocol specification
-
245
User-specified string (location)
Not supported (negative acknowledgment)
246
User-specified string (code)
MAC address as string
247
User-specified string (name)
Not supported (negative acknowledgment)
248
Serial number of the TIM
Not supported (negative acknowledgment)
249 DNP3 implementation level Value of the configured conformity level of the DNP3
master station
250
Product name and model
Order number as string
252
Vendor
SIEMENS AG
Detailed information on DNP3 attributes in the DNP3 device profile
You will find a detailed overview of the attributes and properties specified in the DNP3
protocol and supported by the two DNP3 TIM modules in the DNP3 device profile.
You will find the DNP3 device profiles on the Internet pages of Siemens Automation
Customer Support under the following entry IDs:
