Siemens TIM 4R-IE DNP3 User Manual

The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
196 System Manual, 12/2015, C79000-G8976-C253-04
Parameters in the "Partner" box
From the "Available partners" list, select the DNP3 master station to which the process
values of the data object will be sent. With receiving objects in stations, only one DNP3
master station is normally selected as the data source.
Note
Selection of at least one partner
All partners from which data of the object will be received must be added to the "Selected
partners" list. If you do not enter a partner in the "Selected partners" list, the object will not be
processed.
Partners with communication via node stations
If there is communication between master stations and stations in which the messages are
transfer
red via a node station, for both directions only the destination partner is entered in
the list of selected partners. The node station is not taken into account here.
Inter-station communication (DNP3 dedicated lines)
With inter
-station communication between stations on DNP3 dedicated lines, the messages
are transferred via a node station. In this case, the node station must be selected as the
partner. After being saved in the CPU of the node station, the data is forwarded to the
destination subscriber by a
second object in the node station. In other words, the actual
destination partner is configured in the node station.
Direct node station (Ethernet, dial-up networks)
With direct communication between stations in Ethernet networks and dial
-up networks, onl
y
the communications partner is entered in the list of selected partners. The node station is not
taken into account here.
Name:
Selected partners
Explanation:
The "Selected partners" list displays the communications partners for the
relevant data
object. These are selected from the "Available partners" list
box.
You enter partners in the "Selected partners" list by selecting one or more
(using the Ctrl key) partners in the "Available partners" list and clicking on
the button with the arrow pointing
to the right. The selected partners are then
entered in the "Selected partners" list. The double arrow button is used to
enter all available partners.
With the left arrow button, you remove a selected subscriber from the list of
selected partners.
Up to 8 partners can be configured per data object.
Name:
DNP3 start index
Range of va
l-
ues:
0 ... 32000
