Siemens TIM 4R-IE DNP3 User Manual

The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
205
Table 6- 7 Example of the integration calculation of a threshold value configured with 12
Time [s]
(calculation cycle)
Process value
stored in the
send buffer
Current process
value
Value of the devia-
tion
Integrated
threshold value
0
30
30
0
0
0.5 28 2 1
1.0
30
0
1
1.5
32
2
2
2.0
32
2
3
2.5
34
4
4
3.0
34
4
5
3.5
36
6
6
4.0
34
4
7
4.5
36
6
8
5.0
38
8
9
5.5
36
6
10
6.0
38
8
11
6.5
36
36
6
12
7.0
38
2
1
The configured threshold value of 12 in this example is reached after 6.5 seconds and a new
process value of 36 is entered in the send buffer.
Time trigger
The "Time trigger" is activated with the "Active" option.
A combination of the two alternatives "Time of day" and "Time scheme" is not possible.
If the "Time trigger" is, for example, initially set to "Time of day" and then changed to "Time
scheme", the previously set time of day is deleted.
Name:
Time of day
Range of va
l-
ues:
Time of day (hour and minute)
Default:
Function not active
Explanation:
With a time
-of-day controlled send trigger, the data is read out at the select-
ed time of day.
Name:
Time scheme
Range of va
l-
ues:
Time scheme (hour, minute or second)
Default:
Function not active with the exception of "Mean value send" (Mean04W_S):
Function active, time scheme: 15 minutes
Explanation:
With a time scheme send trigger, the data is read out at the selected inte
r-
vals.
