The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
209
Time [s]
(calculation cycle)
Process value
stored in the
send buffer
Current process
value
Value of the
deviation
Integrated
threshold value
4.5
36
6
8
5.0
38
8
9
5.5
36
6
10
6.0
38
8
11
6.5
36
36
6
12
7.0
38
2
1
The configured threshold value of 12 in this example is reached after 6.5 seconds and a new
process value of 36 is entered in the send buffer.
Time trigger
The "Time trigger" is activated with the "Active" option.
A combination of the two alternatives "Time of day" and "Time scheme" is not possible.
If the "Time trigger" is, for example, initially set to "Time of day" and then changed to "Time
scheme", the previously set time of day is deleted.
Name:
Time of day
Range of
values:
Time of day (hour and minute)
Default:
Function not active
Explanation:
With a time
-of-day controlled send trigger, the data is read out at the
selected time of day.
Name:
Time scheme
Range of
values:
Time scheme (hour, minute or second)
Default:
Function not active with the exception of "Mean value send" (Mean04W_S):
Function active, time scheme: 15 minutes
Explanation:
With a time scheme send trigger, the data is read out at the selected
intervals.
The "Trigger signal" area includes the option of an external send trigger that can be activated
with the "Active" option.
Name:
Trigger signal
Memory area:
The following options are available for the source address:
•
DB: Data block
•
Memory bit: Memory bit area
•
Input: Process input image (PII)
Default:
Function deactivated
