Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 06/2014, C79000-G8976-C253-03
271
● The
Net Data
tab shows the net data of the message.
With the message type 0 and 1 (organizational messages), the data is displayed as plain
text.
with message type 2 and 3 (data messages), the values are displayed.
Note that when analog and counted values are selected, the data in this tab is displayed
as raw values in STEP 7 format and not in DNP3 format.
Figure 7-5
Details
dialog,
Net Data
tab
