Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
274 System Manual, 06/2014, C79000-G8976-C253-03
Figure 7-8
Details
dialog,
Source/Destination/Time stamp
tab
The
Statistics
function provides a statistical evaluation of the entire message protocol in
terms of numbers, types, and throughput of messages of the subscribers involved are sorted
according to
● All messages
● Data messages
● Organizational messages
With the aid of the statistics, you can, for example recognize particular concentrations of
certain message types with individual subscribers allowing you to decide whether normal or
acceptable message traffic is possible in the particular installation.
The
Statistics
dialog displays the statistical data of the TIM message protocol in three tabs.
In each tab, the sampling period of message recalling is displayed at the top. The three tabs
of the dialog list the messages as tables sorted according to the following:
