Installation and commissioning
4.3 Commissioning the TIM
TIM DNP3
72 System Manual, 06/2014, C79000-G8976-C253-03
Figure 4-6 Connecting TIM 3V-IE DNP3 and the TIM 4R-IE DNP3 to the power supply
If one or more TIMs are installed as a CP in an S7-300 device, the CPU and TIMs must be
connected to the same power supply. This ensures that the CPU and TIMs start up at the
same time when the power supply is turned on.
4.3
Commissioning the TIM
4.3.1
Steps in commissioning
Requirements for commissioning
The following requirements must be met for the full commissioning of the TIM:
● Installation and wiring
Installation and wiring is described in the preceding sections.
● Full configuration
The configuration of the TIM is described in the following sections:
Configuration in STEP 7 (Page 79)
The SINAUT Configuration Tool (Page 141)
Steps in commissioning
Commissioning involves the following steps:
1. Turn on the common power supply of the fully wired S7 station.
The LED display during startup is described in the two following sections.
2. Download the configuration data to the station.
Downloading the configuration data is described in the following section:
Downloading (Page 240)
