Simplex 4007ES Programmer's Manual

9-20
4007ES Panel Programmer Manual (579-1167)
Custom Control, Continued
Suppression
Release Device
and Point Types
Suppression release device and point types are shown in the table below. Assign the applicable
device and point types to the suppression points before programming hazard area information.
Refer to section Programming Points inside the Online Help of the 4007ES Panel Programmer
for information on programming the points.
Continued on next page
Table 9-2. Valid Device and Point Types
Point Type Description Valid Device Types AutoGenerates to Following Lists:
RELSIG Releasing
audible circuit
SIGA, SIGB, CHAN2A, CHAN2B, CHAN4A,
CHAN4B, PCHAN4A, PCHAN4B, SIGIAM,
NULLSIG, PS_SIGA, PS_SIGB,
MFIO_SIGA, MFIO_SIGB, MSOUND,
MSIGA, MSIGB, VNAC
L0 - Coding Group 0
L1 - Coding Group 1
L50 - Walk Test Group 0 - signals/relays
L139- Local Mode Operation Points
RELISIG NYC
investigation
bell/strobe
circuit
SIGA, SIGB, CHAN2A, CHAN2B, CHAN4A,
CHAN4B, PCHAN4A, PCHAN4B, SBZAM,
SAZAM, NULLSIG, PS_SIGA, PS_SIGB,
MFIO_SIGA, MFIO_SIGB, MSOUND,
MSIGA, MSIGB, VNAC
L0 - Coding Group 0
L1 - Coding Group 1
L48 - TrueAlert Zone OFF on SILENCE
L50 - Walk Test Group 0 - signals/relays
L139- Local Mode Operation Points
RELVIS Release visual
circuit
SIGA, SIGB, CHAN2A, CHAN2B, CHAN4A,
CHAN4B, PCHAN4A, PCHAN4B, SBZAM,
SAZAM, SIGIAM, NULLSIG, PS_SIGA,
PS_SIGB, MFIO_SIGA, MFIO_SIGB,
MSOUND, MSIGA, MSIGB, VNAC
L0 - Coding Group 0
L13 - Fire Alarm Visuals OFF on RESET
L49 - TrueAlert Zone OFF on RESET
L50 - Walk Test Group 0 - signals/relays
L139- Local Mode Operation Points
RELWVIS Releasing
warning visual
signal
SIGA, SIGB, CHAN2A, CHAN2B, CHAN4A,
CHAN4B, PCHAN4A, PCHAN4B, SBZAM,
SAZAM, SIGIAM, NULLSIG, PS_SIGA,
PS_SIGB, MFIO_SIGA, MFIO_SIGB,
MSOUND, MSIGA, MSIGB, VNAC
L0 - Coding Group 0
L13 - Fire Alarm Visuals OFF on RESET
L49 - TrueAlert Zone OFF on RESET
L50 - Walk Test Group 0 - signals/relays
L139- Local Mode Operation Points
SSABRT Shorted
Suppression
Agent Abort
Zone
MONA, MONB, SMONA, SMONB,
SCAN50, 4002MA, 4002MB, IAM, SECIAM,
MAZAM, MBZAM
SSDUMP Shorted
Suppression
Agent Manual
Dump
MONA, MONB, SMONA, SMONB,
SCAN50, 4002MA, 4002MB, IAM, SECIAM,
MAZAM, MBZAM, ADRPUL, CANPUL
L18 - General Fire Alarm Monitor Zones
L30 - Alarm Verification Group 0
L61 - Coding Group 1 - Monitor Zones
L139- Local Mode Operation Points
SUPRELS Suppression
Release Output
RELEASE, SIGA, SIGB, CHAN2A,
CHAN2B, CHAN4A, CHAN4B, PCHAN4A,
PCHAN4B, SBZAM, SIGIAM, SAZAM,
NULLSIG, PS_SIGA, PS_SIGB,
MFIO_SIGA, MFIO_SIGB
SUPRELS
(Graphic24)
Suppression
(Agent
Discharge)
Release Output
OUTPUT
