Simplex 4007ES Programmer's Manual

7-15
4007ES Panel Programmer Manual (579-1167)
Point Editing for TrueAlert Device, Continued
ISO Options Use this device type to edit TrueAlert Isolators. The following editing options are available for
this device:
Repeater Options Use this device type to edit Repeaters.
The 4009 IDNAC Repeater is a TrueAlert ES Addressable device that extends the maximum
wiring distance supported by the IDNAC Signaling Line Circuit (SLC). Consult the 4009
IDNAC Repeater manual 579-1019 for more information. The following editing options are
available for this device:
Table 7-10.TrueAlert Isolator Editing Options
Option Description
Custom Label This field can be used to describe the appliance's function, location, or other
descriptive information.
Table 7-11. Repeater Editing Options
Option Description
Custom Label This field can be used to describe the appliance's function, location, or other
descriptive information.
Current Draw
(Amps)
This information is not available.
Depleted Battery
Cutout
When this option is selected the Repeater shuts itself off after detecting a depleted
battery condition when no AC power is present. This option is de-selected by default.
Repeater
Operation
Select the option that corresponds to the Repeater’s wiring style.
• For local Class B Wiring select "Class B Spur"
• For local Class A Loop Wiring select "Class A Spur"
• For extended Class A Loop Wiring select "Class A Loop"
