Simplex 4007ES Programmer's Manual

9-6
4007ES Panel Programmer Manual (579-1167)
Custom Control, Continued
Selecting User
Program
Note: You cannot write custom control on InfoAlarm switches and LEDs.
The first step in defining a new custom control equation is to add the equation to a User
Programs.
To add a new custom control equation:
1. Right click on one of the user programs, located at the bottom of the program list, and select
Add Equation from the list of options.
Figure 9-8. Add Equation
2. The Custom Control Program Properties dialog (Figure 9-9) appears. Enter a name for the
equation in the Label field and click on OK.
Figure 9-9. Equation Properties
The Equations section of the Custom Control window updates to include the [INPUTS],
[END INPUTS] etc, entries.

Simplex 4007ES Specifications

General

Model	4007ES
Category	Fire Alarms
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
Display	4.3-inch color touchscreen
Power Supply	120/240 VAC, 50/60 Hz
Network Connectivity	Ethernet, RS-232, RS-485
Addressable Points	250
Communication Protocols	MAPNET II
Notification Appliance Circuits	4 NACs
Total Points	250
Annunciation	Yes
Max Devices	250
Max Notification Circuits	4
Communication Ports	RS-232, USB
