9-22
4007ES Panel Programmer Manual (579-1167)
Custom Control, Continued
Suppression
Release Signal
Responses
This section describes the responses of the suppression release signals.
1. Alarm Silence/System Reset
• RELSIG, RELISIG turn off on alarm silence.
• RELSIG, RELISIG resounds after alarm silence when there is a state change on those
signals (for example, 2nd detector activates in a cross-zone, delay expires, abort activated).
• RELVIS, RELWVIS turn off on system reset.
• If not already silenced, RELSIG, RELISIG will turn off on system reset.
• SRP output stays on until system reset.
Suppression
Release Use
Cases
Use Case: Common Configuration
The following use cases share some common configuration, listed in this section. Specific
configuration is listed under each use case.
Panel: A 4007ES IDNAC with the following points.
IDNet points:
• Manual release point: MBZAM with SSDUMP point type at address M1-11-0.
• Automatic Release Points: Two Smoke detector devices with SUPDET point types at
addresses at M1-18-0 and M1-19-0.
• Abort Switches: One IAM with point type SUPABRT at address M1-35-0.
• SRP: One SRP (RELEASE) with point type SUPRELS at address M1-36-0.
True Alert Zone
• SIG913 is configured as RELSIG (Releasing horn circuit) and has at least one audible
device from the IDNAC channel.
• SIG914 is configured as RELWVIS (Releasing Warning Visual Signal) and has at least
one visual device from the IDNAC channel.
AuxNAC
• SIG3 set as SUPRELS point type.
Create a Hazard Area in Custom Control, Suppression Release Wizard
• Create Hazard Area window
1. Hazard Area Name: Area 1
2. Comments: n/a
Continued on next page
