4-1
Chapter 4.
Panel Information and Configuration
Introduction This section focuses on items found in the Panel tab. Information in this section must be
completed and the options must be configured before the job is successfully built.
In this chapter
Notice to users,
Installers, AHJ,
and other
Involved Parties
This product incorporates field programmable software. In order for the product to comply
with the Standard for Control Units and Accessories for Fire alarm systems, UL864, certain
programming features or options must be limited to specific values or not used at all as
indicated in Table 4-1.
Panel Information Panel information provides identification reference for the technicians who created the jobs.
To enter the panel information:
1. Click on the Panel tab and select the General Information sub-tab.
2. Fill out the information requested on the page:
• Panel Information: This section requests information about the panel.
• Branch Information: This section requests information about the branch of the
company and other useful information.
Notice to users, Installers, AHJ, and other
Involved Parties ........................................4-1
Panel Information .................................... 4-1
Passcode Configuration ............................4-8 System Options ........................................ 4-2
Features Configuration .............................4-8 User Access Level Configuration............ 4-7
Table 4-1. Programming Features and Options
Program Feature
or Option
Permitted
in UL864?
(Y/N)
Possible Settings
Settings Permitted
by UL
Editing group properties DC group
tab
Yes
ON until completion
ON until RESET
ON until SILENCE
ON until completion
Editing Custom Control equations
that change sensitivity levels (set
Alarm Thresholds) for ISN- 550
Photo smoke detectors
Yes
3.1
2.6
2.2
1.8
1.4
1.0
3.1
2.6
2.2
LVSUPV - Latching Verified
Supervisory Smoke Detector
No
LVSDUCT - Latching Verified
Supervisory Duct Smoke Detector
No
MACOFIRE - Carbon
Monoxide Fire Algorithm
Yes
COFIRE, COPRI2
COSUPV, UTILITY
COSUPV
UTILITY
Suppression Release Wizard Yes
Immediate Release
(No Delay),
10 Second Delay,
System Reset after
GREATER of
remaining time or 10s,
IRI Abort, Reset
Original Time Delay,
NYC
Immediate Release
(No Delay),
10 Second Delay,
System Reset after
GREATER of
Remaining time or
10s
Continued on next page
