10-9
4007ES Panel Programmer Manual (579-1167)
IP File Transfer, Continued
Type of Transfer In addition to the upload of the CFIG file, other types of information from the Panel can also be
uploaded to the ES Panel Programmer.
• TrueAlert Report: It is a report generated by the panel. It provides information such
as Point ID, Device Type, and Candela rating for all TrueAlert devices.
• TrueNAC Report: It is a report generated by the panel following the completion of a
TrueNAC diagnostic test. The report indicates all devices’ pass or fail status along
with nominal current, predicted worst case current and predicted worst case voltage
threshold at the minimum TPS operating voltage. By selecting this option you can
choose between downloading the report for All TrueAlert devices on all TPSs or only
for the Last TrueNAC diagnostics performed on a specific TPS and SLC.
• Panel Logs: With this selection you can select between uploading an Alarm Log or the
Trouble Log, produced as a result of Alarm or Trouble conditions reported to the
Control Panel, onto the ES Panel Programmer.
• TrueAlarm Status Report: A report providing the following information for each
point:
- Device Number
- Custom Label
- Current Sensitivity of the Point
- Point Status: Normal, Trouble, Alarm
- Almost Dirty Status: Points that are almost dirty have an asterisk in this field to
denote this status.
• TrueAlarm Service Report: A report providing the following information for each
point:
- Device Number
- Custom Label
- Alarm Level (sensitivity level of the device)
- Average Value
- Current Value
- Percent of Alarm: Shows the current value for the sensor. Value is shown as a
percentage of 100 percent (alarm). For example, if the value shown is 9%, it
means that the sensor is currently at 9% of the value required to trigger an alarm.
- Peak Value: Shows the highest value that the sensor has reached. Value is shown
as a percentage of 100 percent (alarm). For example, if the value shown is 9%, it
means that the peak value experienced by the sensor was 9% of the value
required to trigger an alarm.
- Current State: Possible values include Normal, Trouble, Dirty, Excessively Dirty,
and Almost Dirty.
• TrueAlarm CO Service Report: This report provides the following information
regarding the CO devices:
- Custom Label (custom description of device)
- Current Device Value (PPM)
- End-of-Life Date
• Device Status (Normal, Trouble)
IMPORTANT: The following reports can also be transferred to the USB
storage device.
To Next Page
